Vezje | Intel® Z790 Express |
Podnožje | LGA1700 |
Podpora procesorjev | 14., 13., 12. Gen. Intel® Core™, Pentium® Gold, Celeron® procesorje |
RAM Frekvence | 4× DDR5, do 8266 MHz (O.C), do skupaj največ 192 GB Dvokanalna pomnilniška arhitektura, Intel Extreme Memory Profiles (XMP) |
Zvok | Realtek® ALC1220-VB codec, HD Audio, 2/4/5.1/7.1-kanalni, podpora za S/PDIF Out |
Omrežni vmesniki | Žično: Intel® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) Brezžično: Wi-Fi 7 (802.11a, b, g, n, ac, ax, be; 2.4/5/6 GHz), Bluetooth 5.3 |
Razširitvene reže | 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD 2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD 1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4 6 x SATA 6Gb/s connectors |
Notranji priključki | 1 × 24-pin ATX glavno napajanje 2 × 8-pin ATX 12V napajanje 1 x CPU ventilator 1 x CPU ventilator/vodna črpalka 3 x system ventilator 1 x system ventilator/vodna črpalka 3 x addressable RGB Gen2 LED trak 1 x RGB LED trak 4 x M.2 Socket 3 6 x SATA 6Gb/s 1 x front panel 1 x front panel avdio 1 x USB Type-C® z USB 3.2 Gen 2 podporo 1 x USB 3.2 Gen 1 2 x USB 2.0/1.1 2 x Thunderbolt™ add-in card 1 x Trusted Platform Modul 1 x reset gumb 1 x Q-Flash Plus gumb 1 x Clear CMOS gumb 1 x reset jumper 1 x Clear CMOS jumper |
Zunanji priključki | 1 x USB Type-C® z USB 3.2 Gen 2×2 podporo 2 x USB 3.2 Gen 2 Type-A 3 x USB 3.2 Gen 1 4 x USB 2.0/1.1 2 x SMA priključka za anteno (2T2R) 1 x HDMI 1 x DisplayPort 1 x RJ-45 1 x optical S/PDIF Out 2× avdio priključka |
Dimenzije | 30,5 × 24,4 cm ATX |
