Podnožje: | Intel LGA 1700 |
Za procesorje: | 13. Gen. Intel® Core™ Processors, 12. Gen. Intel® Core™, Pentium® Gold in Celeron® Processors |
Format: | ATX, 30,5 × 24,4 cm |
Vezni nabor: | Intel® Z790 |
Pomnilnik: | 4 x DIMM, do 128 GB, DDR5, 7800+(OC) |
Razširitvene reže: | 2 x PCIe 5.0 x16 (x16 ali x8/x8 mode) 1 x PCIe 4.0 x16 (x4, x4/x4 mode) ROG Hyper M.2 kartica (1× PCIe 5.0 SSD ali x2 4.0 SSD) |
Povezovanje: | Žično: Intel® 2.5Gb Ethernet z ASUS LANGuard Brezžično: Wi-Fi 6E 2×2, Bluetooth 5.3 |
Zvočna kartica: | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082 |
Notranji priključki: | 1 × 4-pin CPU Fan 1 × 4-pin CPU OPT Fan 1 × 4-pin AIO Pump 4 × 4-pin Chassis Fan 1 x W_PUMP+ 1 × 2-pin Water In 1 × 2-pin Water Out 1 × 3-pin Water Flow 1 × 24-pin Main Power 2 × 8-pin +12V Power 1 × 6-pin PCIe Power 3 x M.2 slot (Key M) 6 x SATA 6Gb/s 1 x USB 3.2 Gen 2×2 (podpira USB Type-C®) 2 x USB 3.2 Gen 1 podpira dodatne 4 USB 3.2 Gen 1 2 x USB 2.0 podpira dodatne 4 USB 2.0 3 x Addressable Gen 2 1 x AURA RGB header 1 x FlexKey gumb 1 x Front Panel Audio header (AAFP) 1 x Start gumb 1 x ReTry gumb 1 × 10–1 pin System Panel header 1 x Thermal Sensor header 1 x CPU Over Voltage jumper 1 x Alternative PCIe Mode switch |
Zunanji priključki: | 2 x Thunderbolt™ 4 USB Type-C® ports 6 x USB 3.2 Gen 2 (5 x Type-A + 1 x USB Type-C®) 4 x USB 3.2 Gen 1 (4 x Type-A) 1 x HDMI® 1 x Wi-Fi modul 1 x Intel® 2.5Gb Ethernet 5 x pozlačeni avdio priključki 1 x Optical S/PDIF out 1 x BIOS FlashBack™ gumb 1 x Clear CMOS gumb |
